01-020 - FOOTREST

06-050 - ANTI LOCK BRAKE SYSTEM 06-050 - ANTI LOCK BRAKE SYSTEM 07-030 - CLUTCH CONTROL 07-030 - CLUTCH CONTROL 02-040 - COWLING 02-040 - COWLING 02-190 - EMBLEM 02-190 - EMBLEM 09-020 - FILTER CANISTER 09-020 - FILTER CANISTER 01-020 - FOOTREST 01-020 - FOOTREST 01-010 - FRAME 01-010 - FRAME 02-100 - FRAME SIDE COVER 02-100 - FRAME SIDE COVER 06-020 - FRONT BRAKE CALIPER 06-020 - FRONT BRAKE CALIPER 06-040 - FRONT BRAKE CALIPER 06-040 - FRONT BRAKE CALIPER 02-030 - FRONT FENDER 02-030 - FRONT FENDER 04-060 - FRONT FORK 04-060 - FRONT FORK 06-010 - FRONT MASTER CYLINDER 06-010 - FRONT MASTER CYLINDER 05-010 - FRONT WHEEL 05-010 - FRONT WHEEL 09-010 - FUEL TANK 09-010 - FUEL TANK 02-090 - FUEL TANK COVER 02-090 - FUEL TANK COVER 07-020 - HANDLEBAR CONTROLS 07-020 - HANDLEBAR CONTROLS 02-170 - LOCK SET 02-170 - LOCK SET 01-040 - LOWER FAIRING 01-040 - LOWER FAIRING 02-130 - LUGGAGE BOX 02-130 - LUGGAGE BOX 03-350 - REAR BEVEL GEAR 03-350 - REAR BEVEL GEAR 03-340 - REAR DRIVE SHAFT 03-340 - REAR DRIVE SHAFT 02-150 - REAR FENDER 02-150 - REAR FENDER 06-030 - REAR MASTER CYLINDER 06-030 - REAR MASTER CYLINDER 04-080 - REAR SHOCK ABSORBER 04-080 - REAR SHOCK ABSORBER 01-050 - REAR SWING ARM 01-050 - REAR SWING ARM 05-020 - REAR WHEEL 05-020 - REAR WHEEL 02-120 - SEAT 02-120 - SEAT 02-220 - SIDE BAG LEFT 02-220 - SIDE BAG LEFT 02-210 - SIDE BAG RIGHT 02-210 - SIDE BAG RIGHT 01-030 - SIDE STAND 01-030 - SIDE STAND 07-010 - STEERING STEM 07-010 - STEERING STEM
01-020 - FOOTREST
Ref. SKU Description Notes Availability
Price (tax excl.)
1 88733100XNB BRACKET, PILLION FOOTREST LH Available on backorder
€326,01
1
2 88733000XNB BRACKET, PILLION FOOTREST RH Available on backorder
€326,01
1
3 B063134 COVER, FOOTREST RH Available on backorder
€20,52
1
4 B063133 COVER, FOOTREST LH Available on backorder
€20,52
1
5 B064101 PIN, FOOTREST Available on backorder
€5,10
1
6 AP8152385 SCREW TCEI M10X1.25X28 Available on backorder
€5,02
1
7 AP8121133 SPRING Available on backorder
€2,32
1
8 AP8110110 BALL 7 MM Available on backorder
€0,12
1
9 B063309 PLATE Available on backorder
€5,87
1
10 B06382100YE4 FOOTREST, REAR LH Available on backorder
€68,74
1
11 AP8150252 SCREW TCEI M5X20 Available on backorder
€0,35
1
12 AP8134857 PLATE Available on backorder
€9,00
1
13 AP8120573 E-RING 7MM DIN6799 In Stock
€0,54
1
14 AP8150292 WASHER, WAVE Available on backorder
€1,41
1
15 851821 RING NUT Available on backorder
€34,82
1
16 AP8150195 VTCEI M10X30 DA -8.8 UNI 5931 Available on backorder
€1,41
1
17 AP8120001 GROMMET Available on backorder
€4,00
1
18 2B003172 BRACKET, FRONT FOOTREST LH Available on backorder
€259,26
1
19 B06382000YE4 FOOTREST, REAR RH Available on backorder
€68,74
1
20 2B001588 COVER, FRONT FOOTREST LH Available on backorder
€20,78
1
21 2B001733 PLATE Available on backorder
€11,73
1
22 2B001738 FOOTREST, FRONT LEFT Available on backorder
€88,19
1
23 GU30441005 SAFETY PIN Out of Stock
€8,67
24 GU98612225 SCREW Available on backorder
€0,52
1
25 AP8120573 E-RING 7MM DIN6799 In Stock
€0,54
1
26 2B002347 SPRING, FOOTREST Available on backorder
€5,74
1
27 2B003173 BRACKET, FRONT FOOTREST RH Available on backorder
€259,26
1
28 GU98682420 SCREW TCEI M8X20 Available on backorder
€0,75
1
29 GU95008308 WASHER 8.4X18X2 In Stock
€0,96
1
30 CM228401 PIN, FOOTREST Available on backorder
€2,35
1
31 B063907 PIN, FOOTREST Out of Stock
€4,20
32 2B001587 COVER, FRONT FOOTREST RH Available on backorder
€20,78
1
33 2B001739 FOOTREST, FRONT RIGHT Available on backorder
€88,19
1
