A02 - Rear Frame Assembly

A01 - Frame Assembly A01 - Frame Assembly A02 - Rear Frame Assembly A02 - Rear Frame Assembly B01 - Swingarm Assembly B01 - Swingarm Assembly B02 - Rear Suspension Assembly B02 - Rear Suspension Assembly B03 - Front Suspension Assembly B03 - Front Suspension Assembly B04 - Right-Hand Fork B04 - Right-Hand Fork B05 - Left-Hand Fork B05 - Left-Hand Fork C01 -Rear Wheel Assembly C01 -Rear Wheel Assembly C02 - Front Wheel Assembly C02 - Front Wheel Assembly D01 - Left-Hand Footrest Assembly D01 - Left-Hand Footrest Assembly D02 - Right-Hand Footrest Assembly D02 - Right-Hand Footrest Assembly D03 - Right-Hand Handlebar Assembly D03 - Right-Hand Handlebar Assembly D04 - Left-Hand Handlebar Assembly D04 - Left-Hand Handlebar Assembly D05 - Locks D05 - Locks E01 - Front Fairing Mudguards E01 - Front Fairing Mudguards E02 - Fairing Assembly E02 - Fairing Assembly E03 - Airbox Assembly E03 - Airbox Assembly E04 - Fuel Tank Assembly E04 - Fuel Tank Assembly E05 - Rear Fairing Assembly E05 - Rear Fairing Assembly K01 - Versions For Foreign Countries K01 - Versions For Foreign Countries K02 - Carbon Canister Assembly K02 - Carbon Canister Assembly K03 - ABS Braking System K03 - ABS Braking System
A02 - Rear Frame Assembly
Ref. SKU Description Notes Availability
Price (tax excl.)
1 8000C7208 REAR FRAME Available on backorder
€478,70
1
2 800095828 TAMPONE ANTIVIBRANTE Available on backorder
€2,94
1
3 8AA0B2771 SCREW TCIC M3X0.5 In Stock
€1,47
1
4 8C00B2690 VITE TCEIF M8X1,25 L25 In Stock
€1,44
1
5 8000C7253 BUSH Available on backorder
€5,43
1
6 66N021313 CIRCLIP Available on backorder
€0,62
1
7 8A00B5650 VITE SPECIALE M8X1,25-L42 In Stock
€1,54
1
8 MV800069150 BRACKET, SEAT Available on backorder
€7,78
1
9 8000B2712 DADO FRENATO M8X1,25-CH 12 -SP In Stock
€1,30
1
10 8000B2705 NUT M3X0.5 Available on backorder
€1,55
1
11 8000B5959 ROSETTA D12 D7,8 SP0,5 IN NYLO EXCEPT ORO In Stock
€0,51
1
11 8000C9203 WASHER ORO Available on backorder
€0,07
1
12 8000C9343 PIN Available on backorder
€6,52
1
13 8000B5811 DADO A GRAFFETTA M5 In Stock
€1,17
1
14 8A00B5920 VITE M5 PER CARROZZERIA CON ORO In Stock
€1,96
1
14 8000B5920 VITE M5 PER CARROZZERIA CON CO EXCEPT ORO In Stock
€1,17
1
15 8000C8201 FENDER, REAR EXCEPT ORO In Stock
€65,78
1
15 80A0C8121 FENDER, REAR ORO Available on backorder
€672,43
1
16 800094170 MOLLA ARRESTO PEDANA Available on backorder
€3,67
1
17 80A0C4836 BRACKET, PILLION FOOTREST RH Available on backorder
€240,88
1
18 80B0B3578 FOOTREST, REAR RH In Stock
€50,22
1
19 MV6BN021507 BALL 1/4 In Stock
€0,68
1
20 80A0C4835 BRACKET, PILLION FOOTREST LH Available on backorder
€235,52
1
21 8B00B2769 PERNO ROTAZIONE PEDANA In Stock
€2,18
1
22 800094171 BUSSOLA ROTAZIONE PEDANA POST. Available on backorder
€3,18
1
23 80B0B3579 PEDANA POST.SX FINITA In Stock
€45,41
1
24 800090429 ANELLO DI SICUREZZA F 5 Available on backorder
€1,36
1
25 8000B2710 DADO AUTOBLOC.FLANG.M6X1 -CH10 In Stock
€0,95
1
26 8AB0B6742 SCREW, TAPPING 3.5X9.5 EXCEPT ORO Available on backorder
€1,32
1
27 8000C8667 HOLDER, TOOL Out of Stock
€9,93
