B01 - Swing Arm Assembly

A01 - Frame A01 - Frame A02 - Rear Frame Assembly (B3 675-800-800RR) A02 - Rear Frame Assembly (B3 675-800-800RR) A03 - Rear Frame Assembly (Dragster) A03 - Rear Frame Assembly (Dragster) B01 - Swing Arm Assembly B01 - Swing Arm Assembly B02 - Rear Shock Absorber B02 - Rear Shock Absorber B03 - Front Suspension Assembly B03 - Front Suspension Assembly B04 - Right Hand Fork (B3 675) B04 - Right Hand Fork (B3 675) B05 - Left Hand Fork (B3 675) B05 - Left Hand Fork (B3 675) B06 - Right Hand Fork (B3 800-800RR - Dragster) B06 - Right Hand Fork (B3 800-800RR - Dragster) B07 - Left Hand Fork (B3 800-800RR - Dragster) B07 - Left Hand Fork (B3 800-800RR - Dragster) B08 - Steering Damper B08 - Steering Damper C01 - Rear Wheel Assembly C01 - Rear Wheel Assembly C02 - Front Wheel Assembly C02 - Front Wheel Assembly D01 - Left-Hand Footrest Assembly D01 - Left-Hand Footrest Assembly D02 - Right-Hand Footrest Assembly D02 - Right-Hand Footrest Assembly D03 - Right Hand Handlebar Assembly D03 - Right Hand Handlebar Assembly D04 - Left Hand Handlebar Assembly (B3 675-800-800RR - Dragster MY15/16) D04 - Left Hand Handlebar Assembly (B3 675-800-800RR - Dragster MY15/16) D05 - Left Handlebar Assembly (Dragster MY17) D05 - Left Handlebar Assembly (Dragster MY17) D06 - Lock Assy D06 - Lock Assy E01 - Fairing Assembly E01 - Fairing Assembly E02 - Fairing Assembly E02 - Fairing Assembly E03 - Airbox Assembly E03 - Airbox Assembly E04 - Fuel Tank Assembly E04 - Fuel Tank Assembly E05 - Rear Fairing Assembly (B3 675-800-800RR) E05 - Rear Fairing Assembly (B3 675-800-800RR) E06 - Rear Fairing Assembly (Dragster) E06 - Rear Fairing Assembly (Dragster) K01 - Versions For Foreign Countries K01 - Versions For Foreign Countries K02 - Carbon Canister Assembly (B3 675-800-800RR - Dragster MY14-16) K02 - Carbon Canister Assembly (B3 675-800-800RR - Dragster MY14-16) K03 - ABS Braking System (B3 675-800 - Dragster) K03 - ABS Braking System (B3 675-800 - Dragster) K04 - Carbon Canister Assembly (Dragster MY17) K04 - Carbon Canister Assembly (Dragster MY17)
B01 - Swing Arm Assembly
Ref. SKU Description Notes Availability
Price (tax excl.)
1 SPMV8D00B5783 SWINGARM Available on backorder
€1.307,40
1
2 SPMV800084872 SPACER, HUB BEARING Available on backorder
€34,83
1
3 SPMV800084938 BEARING, BALL 25X42X9 Available on backorder
€43,05
1
4 SPMV800084939 CIRCLIP J42X1.75 V Available on backorder
€3,67
1
5 SPMV800084936 BEARING, NEEDLE 25X32X20 Available on backorder
€15,97
1
6 SPMV800084937 SEAL OIL 25X32X4 Available on backorder
€9,25
1
7 SPMV800084859 COLLAR, SWINGARM LH Available on backorder
€32,53
1
8 SPMV800084873 COLLAR, SWINGARM RH Available on backorder
€21,13
1
9 SPMV8000B2762 SAFETY PIN Available on backorder
€7,75
1
10 SPMV800091655 AXLE REAR SWING ARM In Stock
€109,47
1
11 SPMV8A00B5785 UPPER CHAIN SLIDING SHOE MY17 DRAGSTER RR/DRA Available on backorder
€20,20
1
11 SPMV8000B5785 UPPER CHAIN SLIDING SHOE Available on backorder
€19,32
1
12 SPMV8000B5786 SPRING Available on backorder
€18,35
1
13 SPMV8000B5875 BEARING, NEEDLE In Stock
€11,45
1
14 SPMV8D00B2672 SCREW M6 11.7X16 In Stock
€1,28
1
15 SPMV8000B5787 LOWER CHAIN SLIDING SHOE 675, 800, 800RR In Stock
€6,99
1
15 SPMV8000B8471 LOWER CHAIN SLIDING SHOE DRAGSTER, DRAGSTER R In Stock
€8,56
1
16 SPMV800090391 SPACER 15.5X8X6.2 Available on backorder
€1,21
1
17 SPMV8A00B5824 PIN Available on backorder
€23,48
1
18 SPMV8000C0852 WASHER Available on backorder
€1,22
1
19 SPMV8000C0928 KIT SCREW-WASHER Available on backorder
€5,66
1
20 SPMV8000B5874 LABEL WARNING Available on backorder
€5,33
1
21 SPMV8000B2752 SCREW 675, 800, 800RR In Stock
€4,84
1
21 SPMV8A00B2752 SCREW DRAGSTER, DRAGSTER R Available on backorder
€9,25
1
22 SPMV80B0C1104 CHAIN COVER, UPPER DRAGSTER RR LH, DRAG In Stock
€149,01
1
22 SPMV8000B5449 CHAIN COVER, UPPER In Stock
€14,07
1
23 SPMV8000B2798 SPACER WITH COLLAR Available on backorder
€0,73
1
24 SPMV8B00B4221 VITE TBEI M5X0,8 CH3 L14 Available on backorder
€1,61
1
25 SPMV8000C2908 CHAIN COVER, LOWER DRAGSTER RR LH, DRAG Available on backorder
€214,94
1
25 SPMV8000B5782 CHAIN COVER, LOWER 675 Available on backorder
€42,63
1
25 SPMV8000B8342 CHAIN COVER, LOWER 800,800RR,DRAG.,DRAG In Stock
€48,96
1
26 SPMV8000B5907 LABEL DRIVE CHAIN 675 Available on backorder
€6,01
1
26 SPMV8000B8341 LABEL DRIVE CHAIN Available on backorder
€5,26
1
27 SPMV8A00B2672 BOLT, FLANGE M6X12 In Stock
€1,26
1
28 SPMV8B00B2681 SCREW TEF M6X1X12 CH8 In Stock
€0,80
1
28 SPMV8E00B2681 VITE TEF M6X1 CH8 L20 MY17 DRAGSTER RR/DRA In Stock
€1,04
1
29 SPMV8000B9306 BRACKET, REAR FENDER DRAGSTER,DRAGSTER RR In Stock
€388,75
1
30 SPMV8000B8245 FENDER, REAR NUMBER PLATE HOLDER DRAGSTER RR LH, DRAG Available on backorder
€146,77
1
30 SPMV8000B8245 FENDER, REAR NUMBER PLATE HOLDER DRAGSTER, MY15/16 DR Available on backorder
€146,77
1
30 SPMV8000B8245 FENDER, REAR NUMBER PLATE HOLDER MY16/17 DRAGSTER RR Available on backorder
€146,77
1
31 SPMV8A00B3600 PAD, VIBRATION DAMPER DRAGSTER, DRAGSTER R In Stock
€1,16
1
32 SPMV80A0B8891 PLATE STIFFENER DRAGSTER, DRAGSTER R In Stock
€107,63
1
33 SPMV8E00B2672 SCREW TFEI M6X1 D11,7 L14 DRAGSTER, DRAGSTER R In Stock
€1,10
1
34 SPMV8D00B2672 SCREW M6 11.7X16 DRAGSTER, DRAGSTER R In Stock
€1,28
1
35 SPMV80A090392 DISTANZIALE D12 D8 D6 SP5,2 DRAGSTER, DRAGSTER R In Stock
€1,47
1
36 SPMV8D00B2672 SCREW M6 11.7X16 DRAGSTER, DRAGSTER R In Stock
€1,28
1
37 SPMV8000B8247 FLANGE, LICENSE PLATE LOWER DRAGSTER, DRAGSTER R Available on backorder
€42,81
1
38 SPMV8C00B2680 SCREW TEF M5X0.8X12 DRAGSTER, DRAGSTER R In Stock
€0,90
1
39 SPMV8F00B2680 SCREW TEF M5X0.8 DRAGSTER, DRAGSTER R Available on backorder
€1,17
1
40 SPMV800073834 REFLEX REFLECTOR, REAR DRAGSTER, DRAGSTER R In Stock
€7,34
1
41 SPMV8000B2706 DADO AUTOFRENANTE M4 DRAGSTER, DRAGSTER R In Stock
€0,88
1
42 SPMV8000B8248 FLANGE, LICENSE PLATE UPPER DRAGSTER, DRAGSTER R Available on backorder
€26,50
1
43 SPMV8000B9347 SCREW M5X10 DRAGSTER, DRAGSTER R Available on backorder
€1,26
1
44 SPMV8H00B2688 VITE TCEIF M6X1 L35 DRAGSTER, DRAGSTER R In Stock
€1,02
1
45 SPMV8000B8562 COVER, CONNECTOR DRAGSTER, DRAGSTER R In Stock
€3,46
1
46 SPMV80A092658 DISTANZ.CON COLLET.D10 D7,6 D5 DRAGSTER, DRAGSTER R In Stock
€1,27
1
47 SPMV8A00B5919 SCREW M5 DRAGSTER, DRAGSTER R In Stock
€0,92
1
48 SPMV8B0070695 PLUG 675, 800, 800RR In Stock
€0,73
1
49 SPMV800090391 SPACER 15.5X8X6.2 Available on backorder
€1,21
1
49 SPMV8000B3764 SPACER 18X10X9 MY17 DRAGSTER RR/DRA Available on backorder
€0,98
1
50 SPMV8000C3975 COVER, SWING ARM MY17 DRAGSTER RR/DRA In Stock
€40,90
1
51 SPMV8000C3998 COVER, SWING ARM MY17 DRAGSTER RR/DRA In Stock
€42,22
1
52 SPMV8000C3979 PLATE MY17 DRAGSTER RR/DRA Available on backorder
€29,03
1
53 SPMV8000C3980 SPACER MY17 DRAGSTER RR/DRA Available on backorder
€4,48
1
54 SPMV8A00B2694 SCREW M5X12 MY17 DRAGSTER RR/DRA Available on backorder
€0,82
1
