B01 - Swing Arm Assembly

A01 - Frame Assembly A01 - Frame Assembly A02 - Rear Frame Assembly A02 - Rear Frame Assembly B01 - Swing Arm Assembly B01 - Swing Arm Assembly B02 - Rear Suspension Assembly B02 - Rear Suspension Assembly B03 - Front Suspension Assembly B03 - Front Suspension Assembly B04 - Right Hand Fork (F4 S - F4 FT - F4 R) B04 - Right Hand Fork (F4 S - F4 FT - F4 R) B05 - Left Hand Fork (F4 S - F4 FT - F4 R) B05 - Left Hand Fork (F4 S - F4 FT - F4 R) B06 - Steering Damper (F4 S - F4 FT - F4 R) B06 - Steering Damper (F4 S - F4 FT - F4 R) B07 - Steering Damper (F4 RR) B07 - Steering Damper (F4 RR) C01 - Rear Wheel Assembly C01 - Rear Wheel Assembly C02 - Front Wheel Assembly C02 - Front Wheel Assembly D01 - Left Hand Footrest Assembly D01 - Left Hand Footrest Assembly D02 - Right Hand Footrest Assembly D02 - Right Hand Footrest Assembly D03 - Handlebar Assembly (Right Side) D03 - Handlebar Assembly (Right Side) D04 - Handlebar Assembly (Left Side) D04 - Handlebar Assembly (Left Side) D05 - Locks D05 - Locks E01 - Fairing Assembly E01 - Fairing Assembly E02 - Airbox Assembly E02 - Airbox Assembly E03 - Fuel Tank Assembly E03 - Fuel Tank Assembly E04 - Rear Fairing Assembly E04 - Rear Fairing Assembly K01 - Versions For Foreign Countries K01 - Versions For Foreign Countries K02 - Carbon Canister Assembly K02 - Carbon Canister Assembly G16 - Exhaust System G16 - Exhaust System
B01 - Swing Arm Assembly
Ref. SKU Description Notes Availability
Price (tax excl.)
1 8AA0B3614 REAR SWING ARM ASSY F4R, F4RR Available on backorder
€1.812,11
1
1 8A00B3614 REAR SWING ARM ASSY F4S, F4 FRECCE TRICO Available on backorder
€1.712,73
1
2 800084872 DISTANZIALE INTERNO CUSCINETTI Available on backorder
€34,83
1
3 MV800084938 BEARING, BALL 25X42X9 Available on backorder
€43,05
1
4 800084939 CIRCLIP J42X1.75 V Available on backorder
€3,67
1
5 800084936 ASTUC. A RULL. D25-D32-L20 Available on backorder
€15,97
1
6 800084937 ANELLO DI TENUTA D25-D32-L4 Available on backorder
€9,25
1
7 800084859 COLLAR, SWINGARM LH Available on backorder
€32,53
1
8 800084873 COLLAR, SWINGARM RH Available on backorder
€21,13
1
9 8000B2762 PIOLO SUPPORTO PINZA FRENO POS Available on backorder
€7,75
1
10 800048245 DADO ELASTICO M6X1-L16 In Stock
€1,68
1
11 8000B3622 UPPER CHAIN SLIDING SHOE In Stock
€29,76
1
12 800087463 PLATE, FRONT Available on backorder
€10,43
1
13 800089300 REAR PROTECTOR PLATE Available on backorder
€10,53
1
14 8B00B2672 VITE TFEI M6X1 D11,7 L21 In Stock
€0,98
1
15 8000B3623 LOWER CHAIN SLIDING SHOE In Stock
€19,81
1
16 800090391 DISTANZIALE D15,5-D8-D6,2-SP3, Available on backorder
€1,21
1
17 8000B3629 CHAIN GUARD Available on backorder
€33,80
1
18 8B00B2688 VITE TCEIF M6X1-L16 In Stock
€1,17
1
19 800087441 BRACKET, SHOCK ABSORBER Available on backorder
€105,87
1
20 8D00B2691 SCREW TCEIF M10X1.25X31 Available on backorder
€4,01
1
21 800091022 DADO ELASTICO M4X0,7 F4S, F4R, F4RR Available on backorder
€2,06
1
21 8000B4237 GROMMET F4 FRECCE TRICOLORI Available on backorder
€9,08
1
22 8000B5319 KIT COPRICATENA SUPERIORE F4S, F4R, F4RR Available on backorder
€44,15
1
22 8000B5377 CHAIN COVER, UPPER F4 FRECCE TRICOLORI Out of Stock
€0,00
23 800090979 TAMPONE PER FANALE POST. Available on backorder
€3,00
1
24 8A00B2672 VITE TFEI M6X1 D11,7 L12 Available on backorder
€1,26
1
25 8000B3626 COPRICATENA INFERIORE Available on backorder
€34,25
1
25 8000B5378 CHAIN COVER, LOWER F4 FRECCE TRICOLORI Out of Stock
€0,00
26 8000B4015 LABEL DRIVE CHAIN Available on backorder
€3,80
1
27 80A090392 DISTANZIALE D12 D8 D6 SP5,2 Available on backorder
€1,47
1
28 8000A2734 LABEL WARNING Available on backorder
€3,90
1
29 8000B2752 VITE FISSAGGIO MOZZO RUOTA POS In Stock
€4,84
1
30 800091655 AXLE REAR SWING ARM F4S, F4R, F4 FRECCE In Stock
€109,47
1
30 800084864 AXLE REAR SWING ARM F4RR Available on backorder
€113,25
1
31 8000B2728 WASHER In Stock
€1,26
1
32 8000B2751 SCREW TEF M15X1.25X22 Available on backorder
€13,27
1
33 8000A4539 PLUG In Stock
€0,72
1
34 8A0090901 VITE SPECIALE M4X13,7 F4S, F4R, F4RR In Stock
€1,07
1
35 8C00B4869 COLLAR REAR FORK DIST F4RR Available on backorder
€66,18
1
