A02 - REAR FRAME

A01 - FRAME A01 - FRAME A02 - REAR FRAME A02 - REAR FRAME B01 - REAR SWING ARM B01 - REAR SWING ARM B02 - REAR SHOCK ABSORBER B02 - REAR SHOCK ABSORBER B03 - FRONT FORK - HANDLEBAR B03 - FRONT FORK - HANDLEBAR B04 - RIGHT FORK LEG ASSY R B04 - RIGHT FORK LEG ASSY R B05 - LEFT FORK LEG ASSY R B05 - LEFT FORK LEG ASSY R B06 - RIGHT FORK LEG ASSY LUSSO/SCS B06 - RIGHT FORK LEG ASSY LUSSO/SCS B07 - LEFT FORK LEG ASSY LUSSO/SCS B07 - LEFT FORK LEG ASSY LUSSO/SCS C01 - REAR WHEEL C01 - REAR WHEEL C02 - FRONT WHEEL C02 - FRONT WHEEL D01 - LEFT FOOTREST - GEAR CHANGE PEDAL D01 - LEFT FOOTREST - GEAR CHANGE PEDAL D02 - RIGHT FOOTRESTS - BRAKE PEDAL D02 - RIGHT FOOTRESTS - BRAKE PEDAL D03 - FRONT MASTER CYLINDER D03 - FRONT MASTER CYLINDER D04 - CLUTCH CONTROL D04 - CLUTCH CONTROL D05 - LOCK ASSY D05 - LOCK ASSY E01 - COWLING E01 - COWLING E02 - COWLING LOWERS E02 - COWLING LOWERS E03 - INTAKE E03 - INTAKE E04 - FUEL TANK E04 - FUEL TANK E05 - SEAT - TAIL COVER E05 - SEAT - TAIL COVER E06 - FRONT FENDER E06 - FRONT FENDER E07 - WINDSHIELD E07 - WINDSHIELD E08 - SIDE BAGS TV SCS E08 - SIDE BAGS TV SCS K01 - VARIATIONS ABS K01 - VARIATIONS ABS K02 - FILTER CANISTER K02 - FILTER CANISTER K03 - VERSIONS USA-CAN-JPN K03 - VERSIONS USA-CAN-JPN
A02 - REAR FRAME
Ref. SKU Description Notes Availability
Price (tax excl.)
1 80D0C0146 RAIL SEAT, RIGHT Available on backorder
€503,91
1
2 80D0C0147 RAIL SEAT, LEFT Available on backorder
€503,91
1
3 8E00B2690 VITE TCEIF M8 L35 Available on backorder
€1,03
1
4 80A0C0145 FLANGE, REAR PLNTY RING GEAR Available on backorder
€97,85
1
5 8B00B2688 VITE TCEIF M6X1-L16 In Stock
€1,17
1
6 80B0C0148 HANDLE, PILLION RIDER Available on backorder
€266,99
1
7 8C00B2690 VITE TCEIF M8X1,25 L25 In Stock
€1,44
1
8 8000C3659 PLATE Available on backorder
€17,97
1
9 8E00B2672 SCREW TFEI M6X1 D11,7 L14 Available on backorder
€1,10
1
10 8A00C0156 SPECIAL SCREW M10X1.25 Available on backorder
€4,14
1
11 8B00C0294 WHEEL HOUSING Out of Stock
€21,85
12 800063150 DADO ELASTICO M5X0,8-L16 Available on backorder
€0,80
1
13 80A0B5919 SCREW Available on backorder
€0,68
1
14 Available on backorder
€0,00
15 8000C0289 COVER, LOWER Available on backorder
€13,37
1
16 8000C0287 COVER, RH Available on backorder
€28,17
1
17 8000C0773 COVER, LH Available on backorder
€23,65
1
18 Available on backorder
€0,00
19 8000C0292 PLUG R-LUSSO In Stock
€4,13
1
20 8000C0288 COVER, UPPER Available on backorder
€12,98
1
21 8B00B2777 SCREW, TAPPING PH-AB 2,9X13 In Stock
€1,17
1
22 800089293 ANTIVIBRANTE D18-D8-SP7,5 Available on backorder
€1,34
1
23 8000C0290 COVER, RH Available on backorder
€12,24
1
24 8000C0291 COVER, LH Available on backorder
€12,25
1
25 MV8000B2799 SPACER In Stock
€0,88
1
26 8B00B2672 VITE TFEI M6X1 D11,7 L21 Available on backorder
€0,98
1
27 8G00B2688 VITE TCEIF M6X1-L30 SCS-RC SCS In Stock
€0,78
1
28 8000C0426 HOOK SCS-RC SCS Available on backorder
€15,24
1
29 8000B5953 PIOLO DI FISSAGGIO ANT. Available on backorder
€6,60
1
30 800089293 ANTIVIBRANTE D18-D8-SP7,5 Available on backorder
€1,34
1
