019 - PANEL FEANDER SEAT

018 - FUEL TANK 018 - FUEL TANK 019 - PANEL FEANDER SEAT 019 - PANEL FEANDER SEAT 020 - FRAME FOOT RESTS 020 - FRAME FOOT RESTS 20A - DOUBLE SIT KIT 20A - DOUBLE SIT KIT 021 HANDLEBAR AND CONTROLS 021 HANDLEBAR AND CONTROLS 022 - FRONT FORK ASSEMBLY 022 - FRONT FORK ASSEMBLY 023 - REAR SWINGARM AND SUSPENSION 023 - REAR SWINGARM AND SUSPENSION 024 - FRONT WHEEL 024 - FRONT WHEEL 025 - REAR WHEEL 025 - REAR WHEEL 026 - FRONT HYDRAULIC BRAKE 026 - FRONT HYDRAULIC BRAKE 027 - REAR HYDRAULIC BRAKE 027 - REAR HYDRAULIC BRAKE 028 - EXHAUST SYSTEM 028 - EXHAUST SYSTEM 031 - TRANSFER 031 - TRANSFER
019 - PANEL FEANDER SEAT
Ref. SKU Description Notes Availability
Price (tax excl.)
1 F000A00454 SEAT Available on backorder
€85,00
1
2 Y00043928 NUT M8X1.25 H8 CH12 In Stock
€0,85
1
3 F000P00285 FRONT FENDER Available on backorder
€125,47
1
4 Z00067997 SCREW TEF M5X0.8X12 CH8 Available on backorder
€0,20
1
5 F000P00278 SEAT TAIL BRONZE Available on backorder
€54,00
1
5 F0A0P00278 SEAT TAIL LAGOON GREEN Available on backorder
€81,71
1
6 F000P02764 PARAFANGO POSTERIORE Available on backorder
€108,09
1
7 ZH0067545 SCREW TEF M6X1X12 CH8 Available on backorder
€2,50
1
8 800041862 PAD, VIBRATION DAMPER Available on backorder
€0,60
1
9 Z00062727 SCREW TE M6X1X16 CH8 In Stock
€0,50
1
10 8C00B2799 FLANGE BUSH Available on backorder
€3,18
1
11 Z00044240 NUT, SELF LOCKING M6X1 CH10 In Stock
€0,50
1
12 73032132 PLATE Available on backorder
€1,88
1
13 73012329 GUIDE, CABLE Available on backorder
€0,20
1
14 73280100 BRACKET, NUMBER-PLATE Available on backorder
€4,25
1
15 73060039 REFLEX REFLECTOR In Stock
€1,50
1
16 Z00061313 NUT M6X1 H6 CH10 Available on backorder
€0,50
1
17 73012164 GROMMET Available on backorder
€0,20
1
18 ZH0067545 SCREW TEF M6X1X12 CH8 Available on backorder
€2,50
1
19 62ND15504 ROSETTA D12-D6.4-SP1 In Stock
€0,90
1
20 F0A0P00298 COVER FRAME RIGHT Available on backorder
€45,09
1
21 F0A0P00297 COVER FRAME LEFT Available on backorder
€45,09
1
22 73012510 PAD, VIBRATION DAMPER In Stock
€2,65
1
23 73010065 SIDE COVER RUBBER RING In Stock
€0,19
1
24 F000P00310 GUARD FRONT STEP LH Available on backorder
€6,37
1
25 F000P00456 GUARD FRONT STEP RH Available on backorder
€6,45
1
26 ZA0059572 SCREW TBEI M5X0,8X12 Available on backorder
€3,00
1
27 Z00062726 SCREW TEF M6X1X14 In Stock
€1,00
1
28 Z00021535 WASHER 18X6X1.5 Available on backorder
€0,90
1
29 62ND15504 ROSETTA D12-D6.4-SP1 In Stock
€0,90
1
