019 - FRONT FORK ASSEMBLY (RS 300-500R)

017 - AIR FILTER 017 - AIR FILTER 018 - FRAME FOOT RESTS 018 - FRAME FOOT RESTS 019 - FRONT FORK ASSEMBLY (RS 300-500R) 019 - FRONT FORK ASSEMBLY (RS 300-500R) 19A - FRONT FORK ASSEMBLY (SM 500R) 19A - FRONT FORK ASSEMBLY (SM 500R) 020 - REAR SUSPENSION 020 - REAR SUSPENSION 021 - REAR SUSPENSION LINKAGE 021 - REAR SUSPENSION LINKAGE 022 - REAR SWING ARM 022 - REAR SWING ARM 023 - HANDLEBAR AND CONTROLS 023 - HANDLEBAR AND CONTROLS 024 - REAR HYDRAULIC BRAKE 024 - REAR HYDRAULIC BRAKE 025 - PANEL FENDERS SEAT 025 - PANEL FENDERS SEAT 026 - GAS TANK PANEL 026 - GAS TANK PANEL 027 - EXHAUST SYSTEM 027 - EXHAUST SYSTEM 028 - FRONT HYDRAULIC BRAKE (RS 300-500R) 028 - FRONT HYDRAULIC BRAKE (RS 300-500R) 28A - FRONT HYDRAULIC BRAKE (SM 500R) 28A - FRONT HYDRAULIC BRAKE (SM 500R) 029 - FRONT WHEEL (RS 300-500R) 029 - FRONT WHEEL (RS 300-500R) 29A - FRONT WHEEL (SM 500R) 29A - FRONT WHEEL (SM 500R) 030 - REAR WHEEL 030 - REAR WHEEL 033 - TRANSFER (RS 300R) 033 - TRANSFER (RS 300R) 034 - TRANSFER (RS 500R) 034 - TRANSFER (RS 500R) 035 - TRANSFER (SM 500R) 035 - TRANSFER (SM 500R)
019 - FRONT FORK ASSEMBLY (RS 300-500R)
Ref. SKU Description Notes Availability
Price (tax excl.)
1 8000B0522 HANDLEBAR BRACKET, UPPER Available on backorder
€28,90
1
2 8A00B1959 BOLT M8XL30 Available on backorder
€0,80
1
3 8000H2355 HOLDER, HANDLE LOWER Available on backorder
€31,37
1
4 8000H1046 FORK LEGS ASSEMBLY Available on backorder
€700,00
1
5 60ND01222 SCREW TE M10X1,5X8 Available on backorder
€1,20
1
6 8A00A6683 SPACER 32X10X13,5 MM Available on backorder
€13,10
1
7 800060234 WASHER 28X22X10.5X2.5 MM Available on backorder
€0,60
1
8 8000H1385 DAMPER Available on backorder
€0,90
1
9 8000H1714 SPACER 12X10 MM Available on backorder
€0,70
1
10 Z00061314 NUT, SELF LOCKING M10X1.5 Available on backorder
€0,20
1
11 F000P00164 UPPER TRIPLE CLAMP Available on backorder
€178,57
1
12 8E00B1959 SCREW TEF M8X1.25X40 CH12 In Stock
€0,90
1
13 8A0069315 NUT Available on backorder
€10,98
1
14 8A0087717 NUT Available on backorder
€11,99
1
15 800087736 WASHER Available on backorder
€2,50
1
16 800087745 WASHER Available on backorder
€4,20
1
17 F000P00166 LOWER TRIPLE CLAMP WITH PIN Available on backorder
€274,55
1
18 80D0A8481 GUARD FORK TUBE, LH Available on backorder
€10,00
1
19 8000A8423 VITE TE CON COLLETTO M6X1-CH8-L8 Available on backorder
€1,50
1
20 80D0A0633 FORK PROTECTION HOSE CLAMP - RED Available on backorder
€3,70
1
21 ZA0084658 SELF TAPPING SCREW-M5XL20 Available on backorder
€0,20
1
22 80D0A8482 GUARD FORK TUBE, RH Available on backorder
€10,00
1
23 800074842 REFLEX REFLECTOR, SIDE Available on backorder
€2,92
1
24 8000H1400 RH FORK LEG ASSY Available on backorder
€750,00
1
25 8000H1399 LH FORK LEG ASSY Available on backorder
€650,00
1
32 8000H2662 OIL SEAL FORK Available on backorder
€39,80
1
34 8000H2664 SEAL, DUST FRONT FORK Available on backorder
€49,80
1
43 8E00B1959 SCREW TEF M8X1.25X40 CH12 In Stock
€0,90
1
