F06 - FRAME ASSY

F02 - AIR FILTER F02 - AIR FILTER F03 - FUEL TANK & FUEL PUMP F03 - FUEL TANK & FUEL PUMP F04 - REAR FENDER ASSY F04 - REAR FENDER ASSY F05 - SEAT ASSY F05 - SEAT ASSY F06 - FRAME ASSY F06 - FRAME ASSY F07 - WIRE HARNESS BOX F07 - WIRE HARNESS BOX F08 - FOOTREST ASSY F08 - FOOTREST ASSY F09 - SHIFT LEVER & SIDE STAND F09 - SHIFT LEVER & SIDE STAND F10 - HANDLEBAR & SWITCHES F10 - HANDLEBAR & SWITCHES F11 - FRONT FORK ASSY F11 - FRONT FORK ASSY F12 - FORK ASSY F12 - FORK ASSY F13 - REAR SHOCK ABSORBER F13 - REAR SHOCK ABSORBER F14 - FRONT WHEEL F14 - FRONT WHEEL F15 - REAR WHEEL F15 - REAR WHEEL F16 - FRONT BRAKE F16 - FRONT BRAKE F17 - REAR BRAKE F17 - REAR BRAKE F18 - EXHAUST SYSTEM F18 - EXHAUST SYSTEM F19 - HEADLAMP & DASHBOARD ASSY F19 - HEADLAMP & DASHBOARD ASSY F20 - OIL TANK F20 - OIL TANK F21 - LOCK SET F21 - LOCK SET
F06 - FRAME ASSY
Ref. SKU Description Notes Availability
Price (tax excl.)
1 70020069 BOLT Available on backorder
€18,00
1
2 72030992 SCREW-M10X1.25X30 Available on backorder
€4,50
1
3 73032849 BRACKET Available on backorder
€2,00
1
4 73070879 FRONT SUSPENSION MOUNTING PLATE Available on backorder
€25,50
1
5 73012766 ISOLATOR, FRONT SUSPENSION Available on backorder
€48,50
1
6 72020631 NUT-M16X1.5 Available on backorder
€12,50
1
7 72030991 SCREW-M10X1.25X25 Available on backorder
€6,50
1
8 70020068 ENGINE SUSPENSION CONNECTING ROD Available on backorder
€109,50
1
9 73070878 FRONT BRACKET Available on backorder
€33,00
1
10 73070877 BRACKET Available on backorder
€16,00
1
11 72012553 BOLT-M10X1.25X25 Available on backorder
€2,50
1
12 72040814 SPRING WASHER-10MM Available on backorder
€1,00
1
13 72040819 WASHER-D10 Available on backorder
€0,50
1
14 31320031 GROUND STEEL WIRE Available on backorder
€10,50
1
15 73070880 MOUNT, REAR ISOLATOR Available on backorder
€20,00
1
16 73012866 REAR SUSPENSION MOUNTING PLATE Available on backorder
€44,50
1
17 71020540 ENGINE COVER STICKER Available on backorder
€30,00
1
18 71020541 CLUTCH COVER STICKER Available on backorder
€42,50
1
19 72030982 SCREW-M10X1.25X40 Available on backorder
€5,00
1
20 70120461 BUSH-D10XD18X8 Available on backorder
€3,00
1
21 72031082 SCREW-M10X1.5X25 Out of Stock
€0,00
