020 - PANEL FENDERS

018 - FUEL TANK 018 - FUEL TANK 019 - SEATS REAR PANEL PLATE HOLDER 019 - SEATS REAR PANEL PLATE HOLDER 020 - PANEL FENDERS 020 - PANEL FENDERS 021 - FRAME FOOT RESTS 021 - FRAME FOOT RESTS 022 - HANDLEBAR AND CONTROLS 022 - HANDLEBAR AND CONTROLS 023 - FRONT FORK ASSEMBLY 023 - FRONT FORK ASSEMBLY 024 - REAR SUSPENSION 024 - REAR SUSPENSION 025 - REAR SUSPENSION LINKAGE 025 - REAR SUSPENSION LINKAGE 026 - REAR SWINGARM 026 - REAR SWINGARM 027 - FRONT WHEEL 027 - FRONT WHEEL 028 - REAR WHEEL 028 - REAR WHEEL 029 - FRONT HYDRAULIC BRAKE 029 - FRONT HYDRAULIC BRAKE 030 - REAR HYDRAULIC BRAKE 030 - REAR HYDRAULIC BRAKE 031 - EXHAUST SYSTEM 031 - EXHAUST SYSTEM 034 - TRANSFER 034 - TRANSFER
020 - PANEL FENDERS
Ref. SKU Description Notes Availability
Price (tax excl.)
1 F000P03672 FRONT MUDGUARD Available on backorder
€25,00
1
2 8A00A8421 VITE TE CON COLLETTO M5X1-CH8-L12 Available on backorder
€1,50
1
3 F0A0P03781 PAINTED HEADLIGHT COVER RING Available on backorder
€26,38
1
4 F000P03912 SOCKET THREAD CUTTING SCREW-D3-L7 Available on backorder
€0,30
1
5 F000P03668 HEADLIGHT COVER Available on backorder
€12,00
1
6 F000P03669 DASHBOARD COVER Available on backorder
€20,00
1
7 F000P03677 CABLE SUPPORT Available on backorder
€3,85
1
8 F000P03887 NUT CLAMP-M5-15.2X12 Available on backorder
€0,50
1
9 F000P03679 IGNITON LOCK RUBBER HOUSING Available on backorder
€10,66
1
10 F000P03680 LOWER INNER FAIRING Available on backorder
€33,00
1
11 F000P03681 LOWER OUTER FAIRING Available on backorder
€8,00
1
12 F000P03664 RIGHT SIDE FAIRING Available on backorder
€15,00
1
13 F000P03665 LEFT SIDE FAIRING Available on backorder
€15,00
1
14 F000P03798 SCREW-M8-L20 Available on backorder
€0,50
1
15 F000P03088 SPACER Available on backorder
€5,00
1
16 F000P03675 INNER MUDGUARD Available on backorder
€13,99
1
17 8000A8421 VITE TE CON COLLETTO M5X1-CH8-L8 Available on backorder
€2,00
1
18 F000P03887 NUT CLAMP-M5-15.2X12 Available on backorder
€0,50
1
19 F000P03678 REAR MUDGUARD Available on backorder
€27,86
1
20 8000A8421 VITE TE CON COLLETTO M5X1-CH8-L8 Available on backorder
€2,00
1
21 F000P03929 RUBBER PAD Available on backorder
€4,00
1
22 F000P03919 SILENT-BLOCK Available on backorder
€1,50
1
