022 - FUEL TANK ASSY

016 - AIR FILTER ASSY 016 - AIR FILTER ASSY 017 - BRAKE SYSTEM FRONT 017 - BRAKE SYSTEM FRONT 018 - BRAKE SYSTEM REAR 018 - BRAKE SYSTEM REAR 019 - ANTI - LOCK BRAKING SYSTEM ABS 019 - ANTI - LOCK BRAKING SYSTEM ABS 020 - FOOTREST ASSY 020 - FOOTREST ASSY 021 - FRONT ALLOY WHEEL ASSY 021 - FRONT ALLOY WHEEL ASSY 022 - FUEL TANK ASSY 022 - FUEL TANK ASSY 023 - FRONT FENDER ASSY 023 - FRONT FENDER ASSY 024 - RADIATOR COOLING SYSTEM 024 - RADIATOR COOLING SYSTEM 025 - REAR FENDER ASSY 025 - REAR FENDER ASSY 026 - REAR ALLOY WHEEL ASSY 026 - REAR ALLOY WHEEL ASSY 027 - SEAT ASSY 027 - SEAT ASSY 028 - SILENCER ASSY 028 - SILENCER ASSY 029 - STEERING 029 - STEERING 030 - FRONT FORK ASSY 030 - FRONT FORK ASSY 031 - FRONT FORK MOUNTINGS 031 - FRONT FORK MOUNTINGS 032 - FAIRING ASSY 032 - FAIRING ASSY 034 - SIDE PANEL ASSY 034 - SIDE PANEL ASSY 035 - FRAME ASSY - FRAME - MOUNTINGS SIDE STAND 035 - FRAME ASSY - FRAME - MOUNTINGS SIDE STAND 036 - ENGINE MOUNTING SYSTEM 036 - ENGINE MOUNTING SYSTEM 037 - HANDLE BAR ASSY 037 - HANDLE BAR ASSY 038 - SWING ARM ASSY - REAR SHOCK ABSORBER 038 - SWING ARM ASSY - REAR SHOCK ABSORBER 041 - DECALS 041 - DECALS
022 - FUEL TANK ASSY
Ref. SKU Description Notes Availability
Price (tax excl.)
1 T1501PB10140N GASKET FUEL SENSOR UNIT B101 Available on backorder
€1,92
1
2 T10050B10010N FUEL MODULE Available on backorder
€329,99
1
3 T10050B10020N FUEL PUMP MOUNTING BRACKET Available on backorder
€4,14
1
4 TSF0401132 WASHER M6 (6.5 X 12 X 2) Available on backorder
€0,54
1
5 SP0306006 SCREW TCEI M6X12 UNI 5931 Available on backorder
€1,22
1
6 SF0705068 CLAMP SPRING BAND 10 5X8 4X0 8 Available on backorder
€0,77
1
7 T10000B10270N FUEL TUBE PUMP TO FILTER_B102 Available on backorder
€10,18
1
8 MH00900000800 SUPPORT FILTER Available on backorder
€2,25
1
9 T10000KW0340N FILTER FUEL Available on backorder
€7,70
1
10 T10000B10280N FUEL HOSE FILTER TO CONNECTOR_B102 Available on backorder
€13,75
1
11 T10050KE0070N QUICK FUEL CONNECTOR 1 Available on backorder
€13,32
1
12 T10050KE0030N CLAMP 14 MM FUEL HOSE TO CONNECTOR Available on backorder
€0,99
1
13 T10000J20250N HOSE TANK TO ROLLOVER VALVE Available on backorder
€4,07
1
14 T10000KW0170N ROLL OVER VALVE GROMMET Available on backorder
€1,13
1
15 T10000KW0040N ROLL OVER VALVE Available on backorder
€5,36
1
16 T10000B10250N HOSE ROLLOVER VALVE TO CANISTER_B102 Available on backorder
€4,37
1
17 95002-02080 CLIP TUBE B8 Available on backorder
€0,54
1
18 T10050B10070N CONNECTOR FUEL HOSE Available on backorder
€4,23
1
19 T10000J20240N FUEL TUBE INLET Available on backorder
€6,61
1
20 T10050KE0100N SPRING BAND CLAMP DIA 11.5MM Available on backorder
€0,90
1
21 T10010B10310N FLS MOUNTING STEP BOLT Available on backorder
€2,12
1
22 T1501PB10120N FUEL SENSOR UNIT B101 Available on backorder
€29,16
1
23 T10020KW0020N LAYOUT STICKER PETROL TYPE INFO Available on backorder
€0,59
1
24 T1501NB10060N LOCK SET B102 Available on backorder
€109,09
1
25 T1002AB10020N FUEL TANK CAP WITH KEY Available on backorder
€168,98
1
26 T10010B10320C FUEL TANK ASSEMBLY BLUE SILVER DT BLUE SILVER DT Available on backorder
€354,00
1
26 T10010B10320G FUEL TANK ASSY OLIVE GREEN IVORY GLOS DT GREEN IVORY GLOSS DT Available on backorder
€362,85
1
26 T10010B10320A FUEL TANK ASSEMBLY RED GREY DT RED GREY DT Available on backorder
€356,95
1
26 T10010B10320L FUEL TANK ASSEMBLY GREY WHITE DT GREY WHITE DT Available on backorder
€354,00
1
26 T10010B10320E FUEL TANK ASSEMBLY GLOSS EBONY BLACK EBONY GLOSS BLACK ST Available on backorder
€356,95
1
26 T10010B10320D FUEL TANK ASSEMBLY YELLOW GLOSS AND GLO YELLOW SILVER DT Available on backorder
€351,05
1
27 T13000B10420N KIT STEERING LOCK WITH KEY (B102) Available on backorder
€26,60
1
28 T13000B10430N KIT IGNITION SWITCH WITH KEY (B102) Available on backorder
€43,25
1
