F08 - FORK ASSY

F02 - RADIATOR ASSY F02 - RADIATOR ASSY F03 - AIR FILTER F03 - AIR FILTER F04 - FRAME ASSEMBLY F04 - FRAME ASSEMBLY F05 - FRONT FORK ASSEMBLY F05 - FRONT FORK ASSEMBLY F06 - REAR SHOCK ABSORBER ASSEMBLY F06 - REAR SHOCK ABSORBER ASSEMBLY F07 - EQUALIZER/TIE ROD F07 - EQUALIZER/TIE ROD F08 - FORK ASSY F08 - FORK ASSY F09 - HANDLEBAR AND CONTROLS F09 - HANDLEBAR AND CONTROLS F10 - REAR BRAKE PUMP COMBINATION F10 - REAR BRAKE PUMP COMBINATION F11 - ABS UNIT COMBINATION F11 - ABS UNIT COMBINATION F12 - FRONT FENDER/REAR FENDER ASSY F12 - FRONT FENDER/REAR FENDER ASSY F13 - FUEL TANK/FUEL PUMP COMBINATION F13 - FUEL TANK/FUEL PUMP COMBINATION F14 - CHARCOAL CANISTER/SOLENOID VALVE F14 - CHARCOAL CANISTER/SOLENOID VALVE F15 - EXHAUST SYSTEM F15 - EXHAUST SYSTEM F16 - MASTER CYLINDER COMBINATION F16 - MASTER CYLINDER COMBINATION F17 - FRONT WHEEL F17 - FRONT WHEEL F18 - REAR WHEEL F18 - REAR WHEEL F21 - OIL AND GAS SEPARATOR F21 - OIL AND GAS SEPARATOR F22 - DECAL F22 - DECAL
F08 - FORK ASSY
Ref. SKU Description Notes Availability
Price (tax excl.)
1 8A00H2196 ASS.FORCELLONE Available on backorder
€737,60
1
2 Z00071622 BUSHING, SWING ARM Available on backorder
€3,30
1
3 800076283 BEARING, NEEDLE 22X28X11 Available on backorder
€7,50
1
4 800032388 WASHER 26X17.2X1.5 Available on backorder
€1,00
1
5 8A0071621 BUSHING, SWING ARM 58.5 MM Available on backorder
€10,90
1
6 FA00P00173 AXLE, REAR FORK Available on backorder
€51,47
1
7 800075160 RIVET Available on backorder
€0,50
1
8 8000B1166 TUBE GUIDE LEDGE Available on backorder
€5,00
1
9 800069282 BUSH 14X7X5.25 MM In Stock
€0,60
1
10 Z00020536 SCREW SELF-TAPPING 4.8X13 Available on backorder
€0,10
1
11 Y00043928 NUT M8X1.25 H8 CH12 Available on backorder
€0,85
1
12 800071621 BUSHING, SWING ARM 49.5 MM Available on backorder
€10,90
1
13 800096944 CHAIN BAR ADJUSTER Available on backorder
€8,32
1
14 Z00008536 WASHER 13X8.4X2 Available on backorder
€0,90
1
15 Z00017810 NUT M8X1.25 H8 CH12 Available on backorder
€0,60
1
16 ZC0061121 SCREW TE M8X1.25 Available on backorder
€0,70
1
17 800096941 ADJUSTER, CHAIN LH Available on backorder
€8,06
1
18 Z00062729 SCREW TEF M6X1X25 CH8 Available on backorder
€0,20
1
19 Z00062795 SCREW TEF M8X1.25X50 CH12 Available on backorder
€3,00
1
20 F000P00595 CHAIN OUTER GUIDE PLATE Available on backorder
€12,50
1
21 F000P01358 CHAIN INNER GUIDE PLATE Available on backorder
€8,15
1
22 Z00071623 NUT FLANGE M16X1.5 Available on backorder
€2,80
1
23 ZA0067997 SCREW TEF M5X0.8X16 CH8 In Stock
€0,20
1
24 8A0069282 SPACER 14X7X5.25 MM In Stock
€0,60
1
25 Z00036137 WASHER 11X5.5X1.5 MM Available on backorder
€0,90
1
26 ZC0067997 SCREW M5X20 Available on backorder
€5,50
1
27 8000H3033 OVAL-SHAPED WASHER Available on backorder
€2,00
1
28 8AB073909 GUARD, CHAIN Available on backorder
€4,90
1
29 8000H2125 SPACER Available on backorder
€0,90
1
30 Z00056443 NUT, SELF LOCKING M5X0.8 H6 Available on backorder
€0,70
1
31 8000H1320 BUFFER, CHAIN TOUCH DEFENSE Available on backorder
€9,50
1
32 Z00067997 SCREW TEF M5X0.8X12 CH8 Available on backorder
€0,20
1
