F12 - FORK ASSY

F02 - AIR CLEANER ASSY F02 - AIR CLEANER ASSY F03 - FUEL TANK FUEL PUMP COMBINATION F03 - FUEL TANK FUEL PUMP COMBINATION F04 - FRAME ASSEMBLY I F04 - FRAME ASSEMBLY I F05 - HANDLEBAR AND CONTROLS F05 - HANDLEBAR AND CONTROLS F06 - FRAME ASSEMBLY II F06 - FRAME ASSEMBLY II F08 - FRONT FORK ASSEMBLY F08 - FRONT FORK ASSEMBLY F09 - REAR FENDER ASSY F09 - REAR FENDER ASSY F10 - FOOTPEGS AND REARSETS F10 - FOOTPEGS AND REARSETS F11 - SEAT ASSY F11 - SEAT ASSY F12 - FORK ASSY F12 - FORK ASSY F13 - WHEELS F13 - WHEELS F14 - EXHAUST SYSTEM F14 - EXHAUST SYSTEM F15 - HYDRAULIC BRAKE ABS SYSTEM F15 - HYDRAULIC BRAKE ABS SYSTEM F16 - RADIATOR ASSY F16 - RADIATOR ASSY F17 - SIDE CAR FENDER F17 - SIDE CAR FENDER F18 - BASKET ABSORBER F18 - BASKET ABSORBER F19 - SIDE CAR FRAME F19 - SIDE CAR FRAME F20 - BASKET ASSY F20 - BASKET ASSY F21 - LOWER BODY/BASKET SEAT F21 - LOWER BODY/BASKET SEAT F22 - GOOD SHELVES F22 - GOOD SHELVES F23 - BULLET BOX F23 - BULLET BOX F25A - DECAL (SILVER GREY) F25A - DECAL (SILVER GREY) F25B - DECAL (WHITE) F25B - DECAL (WHITE)
F12 - FORK ASSY
Ref. SKU Description Notes Availability
Price (tax excl.)
1 41041204 REAR FORK Out of Stock
€0,00
2 72040865 WASHER-D20 Out of Stock
€0,00
3 70030274 AXLE, REAR FORK Out of Stock
€0,00
4 72020653 NUT-M14×1.5 Out of Stock
€0,00
5 73110089 BUFFER CHAINCASE DEFENCE Out of Stock
€0,00
6 72031030 SCREW M6X12 Out of Stock
€0,00
7 73032512 WASHER Out of Stock
€0,00
8 72040841 WASHER D6 Out of Stock
€0,00
9 72040843 SPRING WASHER D6 Out of Stock
€0,00
10 72031031 BOLT M6×16 Out of Stock
€0,00
11 54120217 CHAIN Out of Stock
€0,00
12 41070734 REAR SHOCK ABSORBER Out of Stock
€0,00
13 72020656 NUT-M10X1.25 Out of Stock
€0,00
14 72040839 WASHER D12 Out of Stock
€0,00
15 72031049 SCREW M10X1.25X40 Out of Stock
€0,00
16 73033035 PLATE Out of Stock
€0,00
17 54140171 CHAIN ADJUSTER ASSY Out of Stock
€0,00
21 41280544 END PIPE Out of Stock
€0,00
22 72040838 WASHER-D10 Out of Stock
€0,00
23 72040845 SPRING WASHER D10 Out of Stock
€0,00
24 73080296 CHAIN BOX Out of Stock
€0,00
