F19 - SIDE CAR FRAME

F02 - AIR CLEANER ASSY F02 - AIR CLEANER ASSY F03 - FUEL TANK FUEL PUMP COMBINATION F03 - FUEL TANK FUEL PUMP COMBINATION F04 - FRAME ASSEMBLY I F04 - FRAME ASSEMBLY I F05 - HANDLEBAR AND CONTROLS F05 - HANDLEBAR AND CONTROLS F06 - FRAME ASSEMBLY II F06 - FRAME ASSEMBLY II F08 - FRONT FORK ASSEMBLY F08 - FRONT FORK ASSEMBLY F09 - REAR FENDER ASSY F09 - REAR FENDER ASSY F10 - FOOTPEGS AND REARSETS F10 - FOOTPEGS AND REARSETS F11 - SEAT ASSY F11 - SEAT ASSY F12 - FORK ASSY F12 - FORK ASSY F13 - WHEELS F13 - WHEELS F14 - EXHAUST SYSTEM F14 - EXHAUST SYSTEM F15 - HYDRAULIC BRAKE ABS SYSTEM F15 - HYDRAULIC BRAKE ABS SYSTEM F16 - RADIATOR ASSY F16 - RADIATOR ASSY F17 - SIDE CAR FENDER F17 - SIDE CAR FENDER F18 - BASKET ABSORBER F18 - BASKET ABSORBER F19 - SIDE CAR FRAME F19 - SIDE CAR FRAME F20 - BASKET ASSY F20 - BASKET ASSY F21 - LOWER BODY/BASKET SEAT F21 - LOWER BODY/BASKET SEAT F22 - GOOD SHELVES F22 - GOOD SHELVES F23 - BULLET BOX F23 - BULLET BOX F25A - DECAL (SILVER GREY) F25A - DECAL (SILVER GREY) F25B - DECAL (WHITE) F25B - DECAL (WHITE)
F19 - SIDE CAR FRAME
Ref. SKU Description Notes Availability
Price (tax excl.)
1 41012086 BASKET FRAME Out of Stock
€0,00
2 50010350 FOOT BOARD,BASKET Out of Stock
€0,00
3 72040837 WASHER 8MM Out of Stock
€0,00
4 72020650 NUT M8X18 Out of Stock
€0,00
5 72012600 BOLT M10×20×1.5 Out of Stock
€0,00
6 72040845 SPRING WASHER D10 Out of Stock
€0,00
7 72040842 WASHER D10 Out of Stock
€0,00
8 72020659 NUT M10×1.5 Out of Stock
€0,00
9 73012457 BASKET BUFFER RUBBER Out of Stock
€0,00
10 72012602 BOLT M10×55 Out of Stock
€0,00
11 72020651 NUT M10×1.25 Out of Stock
€0,00
12 50010346 SIDE CAR FRAME TO ADJUST TUBE Out of Stock
€0,00
13 50010090 CARDON JOINT,FRAME Out of Stock
€0,00
14 50010091 BUSH,JOINT PART Out of Stock
€0,00
15 50010289 BEFORE ADJUSTING ROD ASSEMBLY Out of Stock
€0,00
16 50010290 AFTER ADJUSTING ROD ASSEMBLY Out of Stock
€0,00
17 50010088 REGULATING ROD CONNECTIONS PEDESTAL Out of Stock
€0,00
18 50010107 REGULATING ROD CONNECTIONS PEDESTAL Out of Stock
€0,00
19 72020660 NUT M16×1.5 Out of Stock
€0,00
20 72031061 SCREW M10X30X1.25 Out of Stock
€0,00
21 72020652 NUT M12×1.25 Out of Stock
€0,00
22 72031062 BOLT M12X1.25X45 Out of Stock
€0,00
23 72031047 SCREW M10X25 Out of Stock
€0,00
24 50010344 SIDE FRAME CONNECTION PIPE Out of Stock
€0,00
25 72031049 SCREW M10X1.25X40 Out of Stock
€0,00
